Features
- Provides high pressure fluid control
- Used in hydrostatic testing
- Used in chemical injection
- Used to control back pressure of water jet operations
- 15,000 psi working pressure
- Flow Cv = 1.84, 6 gpm @10 psi dP
BPR10-15 Advanced Features
- Valve Stem
- Spring Cylinder
- Spring Guide
- Male Packing Adapter
- Valve Seat
- Valve Stem Retaining Insert
- Valve Body
- 3/4″ – 16, Lock Nut
- Pressure Adjustment Bolt
- Bellville Washer
- Packing
- Packing Spring
- Packing Barrel O-Ring
- 1/2″ NPT Plug Steel 15K PSI
